| Fan Model:FB5-P8-D800(60Hz) |
|
|
DIA&Blade
|
HP
|
PH
|
RPM
|
Voltage(V)
|
Name AMPS(A)
|
Running AMPS(A)
|
Fan Volume
|
Dynamic Pressure(Pa)
|
dBa
|
Weigh(kg)
|
|
32＇* 5wing
|
1/2
|
3
|
850
|
460
|
1.10
|
1.05
|
8100CFM
|
35
|
60
|
34
|
|
230
|
2.20
|
2.10
|
Fan Model:FB5-P8-D800(50Hz)
DIA&Blade |
Power |
PH |
RPM |
Voltage(V) |
Name AMPS(A) |
Running AMPS(A) |
Fan Volume |
Dynamic Pressure(Pa) |
dBa |
Weigh(kg) |
32＇* 5wing |
370 |
3 |
720 |
380-415 |
1.2 |
1.0 |
11000m3/h |
33 |
58 |
34 |
 Protection
class IP55 Insulation class F
Naming
rules:F=Fan B5=Five
Blades P8=Eight Poles D800=The diameter of impeller is 800mm.
Sound
level is measured at 2m from the motor when the fan is working
on transformer.
|
