Fan Model:FB4-P8-D660(60Hz)
DIA&Blade
HP
PH
RPM
Voltage(V)
Name AMPS(A)
Running AMPS(A)
Fan Volume
Dynamic Pressure(Pa)
dBa
Weigh(kg)
26'* 4wing
1/6
1
850
208-230
1.40
1.15
5284CFM
36
59
27
110-120
2.80
2.05
26'* 4wing
1/6
3
850
460-480
0.6
0.58
5284CFM
36
59
27
230-240

1.2

1.0

Protection class IP55 Insulation class F

Naming rules:F=Fan B4=Four Blades P8=Eight Poles D660=The diameter of impeller is 660mm.

NOTE:

1.The Fan performance parameters wer measured according to ISO 5801:1997(E)、<<Industry ventilation Fan Testing Standard>>、Experiment type A.

2.Noise levelis measured at 2M from the fan.
